Product Description

Length: 3 days
11am-3pm CT

Prerequisites: CATIA® V5 Fundamentals and Surface Design

Description: This course will teach you how to create flawless, styled shapes from scratch using three-dimensional free-form curves and surfaces or using digitized data. You will also learn how to analyze and improve the quality of existing curves and surfaces.

Topics Covered in This Course:

• Course Requisites: CATIA® FreeStyle Shape Design Essentials
• Introduction to FreeStyle Shape Design
• Using the Curve-based Approach
• Using the Surface Based Approach
• Analyzing Curves and Surfaces
• Master Exercise: Automotive Car
• Master Exercise: Hair Dryer
