Product Description

This course will teach you how to design complex 3D mechanical parts using the Boolean approach. You will learn how to work in a Multi-Model Environment and maintain links between 3D models. You will also learn to analyze designs in order to optimize them.

Course Length: 1.5 days
12pm-3pm CT

Have questions? Click Here for Training FAQ

Prerequisites: CATIA® V5 Fundamentals

Topics Covered in This Course:

• Using 3D Elements to Create a Part
• Sketch Based Features
• Part Manipulations
• Dress-Up Features
• Part Analysis
• Annotations
• Master Exercise: Mobile Phone Bottom Case
