Product Description

Designed for users who would like to become productive quickly in using SOLIDWORKS Motion. This course will teach you how to use the SOLIDWORKS Motion Simulation® package to study the kinematics and dynamic behavior of your SOLIDWORKS assembly models.

Course Length: 4 days
A BLOCK - 8am-11am CT
B BLOCK - 12pm-3pm CT

Have questions? Click Here for Training FAQ

Prerequisites: Knowledge of SOLIDWORKS and the basics of the MotionManager is required. If you are not familiar with the basics of the MotionManager, refer to the built-in tutorial for animations inside the SOLIDWORKS software. Knowledge of basic mechanical engineering concepts is recommended.

Topics Covered in This Course:

• Introduction to Motion Simulation® and Forces
• Building a Motion Model and Post-processing
• Introduction to Contacts, Springs and Dampers
• Advanced Contact
• Curve to Curve Contact
• CAM Synthesis
• Motion Optimization
• Flexible Joints
• Redundancies
• Export to FEA
• Event Based Simulation
