199500
SKU: 6834427429046



Length: 5 days
A BLOCK - 8am-11am CST
B BLOCK - 12pm-3pm CST
C BLOCK - 4pm-7pm CST

Prerequisites: Access to SOLIDWORKS 2019 or newer. Access to SOLIDWORKS Simulation Premium 2019 or newer. Must have attended the basic SOLIDWORKS Simulation Essentials and SOLIDWORKS Essentials classes, or have similar experience with SOLIDWORKS and working basic knowledge of finite elements, basic mechanical principles and basic principles in Vibrations. Experience with the Windows® operating system.

Description: This class will raise your SOLIDWORKS Simulation FEA skills to the next level. It offers hands-on experience for the SOLIDWORKS Simulation Premium nonlinear module. It provides an overview on a wide range of nonlinear structural/mechanical analysis topics. You will learn how to deal with models that exhibit large displacements and/or yielding, discuss and practice the use of many material models available in SOLIDWORKS Simulation and how to drive a non-linear analysis to successful completion.



Topics covered in this course:

Lesson 1:
Large Displacement Analysis

  • Case Study: Hose Clamp
  • Linear Static Analysis
  • Nonlinear Static Study
  • Linear Static Study (Large Displacement)

Lesson 2:
Incremental Control Techniques

  • Case Study: Trampoline
  • Linear Analysis
  • Nonlinear Analysis - Force Control
  • Nonlinear Analysis - Displacement Control

Lesson 3:
Nonlinear Static Buckling Analysis

  • Case Study: Cylindrical Shell
  • Linear Buckling
  • Linear Static Study
  • Nonlinear Symmetrical Buckling
  • Nonlinear Asymmetrical Buckling

Lesson 4:
Plastic Deformation

  • Case Study: Paper Clip
  • Linear Elastic
  • Nonlinear - von Mises
  • Nonlinear - Tresca’s

Lesson 5:
Hardening Rules

  • Case Study: Crank Arm
  • Isotropic Hardening
  • Kinematic Hardening

Lesson 6:
Analysis of Elastomers

  • Case Study: Rubber Pipe
  • Two Constant Mooney-Rivlin (1 Material Curve)
  • 2 Constant Mooney-Rivlin (2 Material Curves)
  • 2 Constant Mooney-Rivlin (3 Material Curves)
  • 6 Constant Mooney-Rivlin (3 Material Curves)

Lesson 7:
Nonlinear Contact Analysis

  • Case Study: Rubber Tube

Lesson 8:
Metal Forming

  • Bending
  • Case Study: Sheet Bending



    Items included with course (to be sent to the shipping address provided):

    SOLIDWORKS training manual

    SOLIDWORKS Simulation Premium: Nonlinear - Instructor Led Online Training
    199500
