Length: 3 days - 9:30am to 1:30pm PST

Prerequisites: Mechanical design experience; completion of SOLIDWORKS Essentials or similar experience.

Description: The SOLIDWORKS Routing Piping and Tubing course explains how to create, edit and manage piping and tubing routes, from the critical routing components and their design requirements to the sub-assemblies that contain the routes.

Topics covered in this course:

  1. Fundamentals of Routing
  2. Piping Routes
  3. Piping Fittings
  4. Tubing Routes
  5. Piping and Tubing Changes
  6. Creating Routing Components
  7. Using P&ID Files
  8. Electrical Ducting, Cable Tray, and HVAC Routes
  9. Piping Skids
  10. Using SOLIDWORKS Content


Items included with course (to be sent to the shipping address provided):

SOLIDWORKS training manual & headset*

*headset is provided for first time online training students

SOLIDWORKS Routing / Piping - Instructor Led Online Training
