Length: 4 days
12pm-3pm CST

Prerequisites:  CATIA Mechanical Design Fundamentals

Description:  This course will teach you how to create a sheet metal part using standard wall, bend, and stamping features. You will see how user features can be incorporated into the design and how to use both standard and user-defined materials. Finally, you will learn how to create a flat pattern and produce a detailed, annotated drawing.

Topics covered in this course:

1. Introduction to Sheet Metal Design
2. Creating Walls and Bends
3. Creating the Detailed Design
4. Reusing Parts and Features
5. Generating Drawings
6. Master Exercise: DVD Support
