Product Description

BioMed Durable Resin V1 is an impact-resistant, biocompatible material for making shatter- and abrasion-resistant medical and dental parts that require body contact. This material is suitable for long-term skin contact (more than 30 days), mucosal membranes (more than 30 hours), and is also appropriate for short-term contact (less than 24 hours) with tissue, bone, and dentin.

This 3D printing resin is available in a 1-liter volume and is compatible with several Formlabs SLA printers, including Form 2, Form 3B, Form 3B+, Form 3BL, Form 4B, and Form 4BL.

This material has passed rigorous biocompatibility testing and is a USP Class VI certified material. BioMed Black Resin is manufactured in Formlabs' FDA-registered, ISO 13485 certified facility.

Resin Color: Translucent Light Blue

Mechanical Properties:

• Ultimate Tensile Strength: 29.1 MPa (4230 psi)
• Tensile Modulus: 994 MPa (144 ksi)
• Elongation at Break: 33%
• Flexural Strength: 21 MPa (92 ksi)
• Flexural Modulus: 643 MPa (3070 ksi)
• Shore Hardness: 75D
• Notched Izod: 98 J/m (1.84 ft-lbf/in
• Unnotched Izod: 1340 J/m (25.1 ft-lbf/in
• Heat Deflection Temp. at 0.45 MPa (65.2 psi): 40°C (104°F)
• Heat Deflection Temp. at 1.8 MPa (261.1 psi): 46°C (115°F)
• Coefficient of Thermal Expansion: 102.9 μm/m/°C (57.17 µin/in/°F)

Sterilization Compatibility

• For details on sterilization compatibilities, visit formlabs.com/medical.

Disinfection Compatibility

• Chemical Disinfection: 70% Isopropyl Alcohol for 5 Minutes

Possible Applications:

Dental, Medical

• Single-use instruments
• Patient-specific instruments
• Impact-resistant end-use devices and components requiring biocompatibility

Compatible 3D Printers:

Redesigned Form 4 Resin Cartridge:

• Faster dispensing
• Fill an empty tank in 2-8 minutes with most resins
• Valve system is 5-10x faster to fill than Form 3
• Cartridge body uses less plastic, resulting in a 63% reduction in plastic waste
• Redesigned cartridge takes up 30% less shelf space

Technical Data Sheet:

Download BioMed Durable Resin V1 Data Sheet
