249500
SKU: 7582045667510



Length: 10 days
A BLOCK - 8am-11am CST
B BLOCK - 12pm-3pm CST
C BLOCK - 4pm-7pm CST

Prerequisites: Mechanical design experience and familiarity with Windows operating system.

Description: This course will teach you about CATIA V5. You will learn how to build simple parts and assemblies in CATIA, and how to make simple drawings of those parts and assemblies.

Topics covered in this course:

  1. Introduction to CATIA
  2. Creating Profiles
  3. Creating Basic Features
  4. Creating Additional Part Features
  5. Creating Dress-up Features
  6. Reusing the Data
  7. Finalizing the Design Intent
  8. Working with Assembly Design
  9. Designing in Context
  10. Creating Drawings (ANSI)
  11. Master Exercise: Drill Press Assembly





        CATIA Fundamentals - Instructor Led Online Training
        249500
